Flow Wrapping Machine

Name: Flow Wrapping Machine
Brand: UFLEX LIMITED (ENGINEERING DIVISION)
Price: 1500000 INR
Availability: InStock

Price 1500000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Flow Wrapping Machine Specification

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Control

Drive Type
Electric

Power
5 Kw Watt (w)

Voltage
220 V / AC / Single Phase / 50 Hz Watt (w)

Weight (kg)
850 Kg. (Approx.) Kilograms (kg)

Dimension (L*W*H)
L=4200 mm., W= 1500 mm., H = 1700 mm. Millimeter (mm)

Flow Wrapping Machine Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Month

Delivery Time
12-16 Week

Main Export Market(s)
Asia, Middle East, Central America, South America, Western Europe, Eastern Europe, North America, Australia, Africa

Main Domestic Market
All India

About Flow Wrapping Machine

FlexHorizontal Flow Wrapping Machine is a very versatile machine which can wrapcylindrical, cubical and irregular shaped solid products like Soap / Bottle /Bearing / Cake / Disposable syringe / Pencil Cells / Ice Cream / Piston Rings /Spark Plug / pre-filled pouches /chocolates/spare parts and Similar Product inpillow pack pouch.

The machine isan operator friendly machine with a speed range of 25 to 150 packs per minute(speed can vary depending upon material). The machine is controlled by PLC(programmable logic control) and provided with an operator friendly MMI (manmachine interface).

Allthe temperature controllers provided in the machine are PID. The machine has abuilt in high sensitivity, high response photo registration to ensure accuratepositioning of the product and cutting of the film even at high speeds which resultsin less wastage of packing material.

The machinecomes with features like automatic pouch length adjustment mechanism,adjustable forming unit for a wide range of roll width, which ensure shortchange over times as well as no change parts.

The machine canbe provided with customized in-feed system in synchronization with themanufacturing process of the customer. This machine can be used to pack theproducts like soap, chocolate bars, disposable syringes, IV Fluid bottles, autospare parts, bearing etc.

Machine can beprovided with an optional attachment like coding unit, overload clutch etc. (atan extra cost).
