Dry Laminator Model Excel

Name: Dry Laminator Model Excel
Brand: UFLEX LIMITED (ENGINEERING DIVISION)
Price: 8500000 INR
Availability: InStock

Get a Price/Quote

MOQ : 1 Piece

Dry Laminator Model Excel Specification

Lamination Speed
200 meters/min

Max Film Width
1300 mm

Membrance Core Size
3 inches

Max Lamination Temp
180°C

Product Type
Dry Laminator

Material
Mild Steel

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Based

Drive Type
AC Drive

Heating System
Hot Air/Thermal Oil

Power Source
Electric

Voltage
220-380 V

Weight (kg)
2200 kg

Dimension (L*W*H)
3400 x 1600 x 2100 mm

Capacity
300-400 meters/hour

Feature
High Productivity, Low Maintenance

Color
Blue-Grey

Type of Rollers
Chrome Plated

Speed
200 meters/min

Input Paper Size
Up to 1300 mm

Suitable Paper
Film, Foil, Paper

Main Drive Motor
AC Servo Motor

Safety Features
Emergency Stop, Overload Protection

Laminating Substrates
Film to Film, Film to Foil, Film to Paper

Film Thickness Range
8 - 100 microns

Noise Level
Low Noise Operation

Adhesive Application
Gravure Coating System

Tension Control
Auto Tension Control System

Unwind/Rewind System
Surface or Centre Drum

Web Guiding System
Fully Automatic Edge Guiding

Operator Panel
Touch Screen HMI

Dry Laminator Model Excel Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Letter of Credit (L/C), Telegraphic Transfer (T/T), Cash in Advance (CID)

Main Export Market(s)
Australia, North America, Eastern Europe, Middle East, Africa, Central America, South America, Western Europe, Asia

Main Domestic Market
All India

About Dry Laminator Model Excel

UFLEX High speed dry laminator - Excel model with digital ac vector grade motors / drive for the purpose of lamination of two different substrates comes to you with amazing features such as :

Taper tension control mechanism.
World renowned thermo regulation system.
State of art management information system for ultimate efficiency in production management giving you the real time trend of important information at your finger tips such as total running time, running time during each shift, Machine stop log stop due to any system fault log etc. MIS can also be tailor made as per customers requirements
Reverse cold seal registration.
Water base smoothening bar assembly for running the water based adhesives.

MACHINE SPECIFICATIONS

Web width	1020/320 mm
Mechanical speed	300 Mtr./min
Maximum Roll Diameter	800/1000 mm
Web guiding Ultrasonic Edge Sensor controlled by Digital Drive

Advanced Adhesive Application with Gravure Coating

The Excel Dry Laminator leverages a gravure coating system to ensure uniform and precise adhesive application. This technology is essential for producing high-quality laminates across diverse substrates including film, foil, and paper. Its versatility makes it ideal for industries requiring optimum finish and bond strength, and its capacity to handle various materials broadens its field of application.

Fully Automatic Operation for Maximum Efficiency

Featuring a PLC-based control system and auto tension control, this laminator provides seamless, accurate operation with minimal manual intervention. The touch screen HMI operator panel offers intuitive control, helping operators regulate speed, temperature, and other critical parameters. Automation enhances productivity while reducing errors and maintenance requirements.

Robust Design Prioritizing Safety and Reliability

Engineered with an emergency stop system, overload protection, and constructed from durable mild steel, the Excel Model ensures operator safety and machine longevity. Low noise operation alongside advanced tension control and AC servo drives ensures efficient and stable performance, even under rigorous industrial use.

FAQs of Dry Laminator Model Excel:

Q: How does the gravure coating system in the Excel Dry Laminator ensure precise adhesive application?

A: The gravure coating system applies adhesive uniformly via engraved rollers for consistent coverage, ensuring high-quality lamination on film, foil, or paper substrates. This technique enhances bonding and prevents uneven application.

Q: What types of materials can be laminated using this model?

A: This laminator supports film-to-film, film-to-foil, and film-to-paper applications, accommodating a wide film thickness range of 8 to 100 microns and materials up to 1300 mm wide.

Q: When is auto tension control important during lamination?

A: Auto tension control is crucial throughout the lamination process to maintain substrate alignment and prevent defects such as wrinkles or misregistration, yielding a smooth, high-quality finish.

Q: Where can the Dry Laminator Model Excel be installed?

A: Designed for industrial use, this machine is ideal for manufacturing plants specializing in flexible packaging or converting operations. Its footprint (3400 x 1600 x 2100 mm) fits well in standard production environments.

Q: What process does the machine follow to ensure safety during operation?

A: It incorporates safety features like an emergency stop button, overload protection, and low-noise operation to create a secure and comfortable working environment for operators.

Q: How does the touch screen HMI improve usage and productivity?

A: The intuitive touch screen HMI allows operators to quickly adjust settings, monitor real-time parameters, and respond swiftly to production demands, leading to higher throughput and reduced downtime.

Q: What are the main benefits of using the Excel Dry Laminator compared to manual or semi-automatic machines?

A: Key advantages include higher productivity with speeds up to 200 meters per minute, superior lamination quality due to automated controls, reduced maintenance, and enhanced safety featuresall contributing to efficient and reliable production.
